Cloud Native Architecture on GCP A Deep Dive

Cloud Native Reference Architecture on GCP

Imagine a modern e-commerce application running in a cloud-native way on GCP. The architecture looks something like this:

Architecture Diagram (description)

• Frontend (React app) → Deployed on Cloud Run for serverless hosting.
• Backend microservices → Deployed on Google Kubernetes Engine (GKE).
• Example services: cart-service, payment-service, order-service.
• Service Mesh → Anthos Service Mesh (Istio) for observability, retries, and service-to-service security.
• Messaging → Pub/Sub for asynchronous event delivery (e.g., order placed → inventory update).
• Database → Cloud Spanner for global transactional consistency.
• CI/CD → Cloud Build + Cloud Deploy for continuous integration and deployment.
• Monitoring & Logging → Cloud Operations Suite (Stackdriver) integrated with GKE and Cloud Run.

Example: Kubernetes Deployment on GKE

Here’s a sample YAML manifest for deploying a cart service to GKE:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: cart-service
  labels:
    app: cart
spec:
  replicas: 3
  selector:
    matchLabels:
      app: cart
  template:
    metadata:
      labels:
        app: cart
    spec:
      containers:
      - name: cart-container
        image: gcr.io/my-project/cart-service:latest
        ports:
        - containerPort: 8080
        resources:
          requests:
            cpu: "250m"
            memory: "256Mi"
          limits:
            cpu: "500m"
            memory: "512Mi"
---
apiVersion: v1
kind: Service
metadata:
  name: cart-service
spec:
  selector:
    app: cart
  ports:
    - protocol: TCP
      port: 80
      targetPort: 8080
  type: ClusterIP

This YAML:

• Deploys the cart-service with 3 replicas.
• Exposes it internally using a ClusterIP service.
• Enforces resource requests/limits for predictable scaling.

Example: Cloud Run Deployment (Serverless Backend)

For lightweight services or APIs, Cloud Run makes deployment even simpler. Here’s a sample YAML for deploying with Cloud Run service configuration:

apiVersion: serving.knative.dev/v1
kind: Service
metadata:
  name: payment-service
  namespace: default
spec:
  template:
    spec:
      containers:
        - image: gcr.io/my-project/payment-service:latest
          resources:
            limits:
              cpu: "1"
              memory: "512Mi"
      containerConcurrency: 80
      timeoutSeconds: 300

This YAML:

• Deploys the payment-service as a container to Cloud Run.
• Scales automatically based on requests (down to zero).
• Configures concurrency and timeout.

Adding a Service Mesh with Anthos

With Anthos Service Mesh (Istio), you gain advanced features like mutual TLS (mTLS), retries, and observability. Here’s an example Istio VirtualService YAML for routing traffic:

apiVersion: networking.istio.io/v1alpha3
kind: VirtualService
metadata:
  name: cart-routing
spec:
  hosts:
  - cart-service
  http:
  - route:
    - destination:
        host: cart-service
        subset: v1
      weight: 90
    - destination:
        host: cart-service
        subset: v2
      weight: 10

This YAML:

• Routes 90% of traffic to v1 and 10% to v2 of the cart-service.
• Enables canary deployments with zero downtime.

CI/CD with Cloud Build

To automate deployments, you can use Cloud Build with a cloudbuild.yaml:

steps:
- name: 'gcr.io/cloud-builders/docker'
  args: ['build', '-t', 'gcr.io/$PROJECT_ID/cart-service:$COMMIT_SHA', '.']

- name: 'gcr.io/cloud-builders/docker'
  args: ['push', 'gcr.io/$PROJECT_ID/cart-service:$COMMIT_SHA']

- name: 'gcr.io/cloud-builders/kubectl'
  args: ['apply', '-f', 'k8s/deployment.yaml']
  env:
  - 'CLOUDSDK_COMPUTE_REGION=us-central1'
  - 'CLOUDSDK_CONTAINER_CLUSTER=my-gke-cluster'

Benefits of This Approach

• Portability – Workloads run in containers, portable across environments.
• Scalability – Automatic scaling in GKE and Cloud Run.
• Resilience – Self-healing workloads and retries via Istio.
• Faster Delivery – Automated pipelines with Cloud Build + Cloud Deploy.
• Global Reach – Backed by Google’s networking and databases like Spanner.

Conclusion

Cloud-native architecture on GCP provides everything you need to build modern, scalable, and resilient applications. By combining GKE, Cloud Run, Anthos Service Mesh, and Cloud Build, teams can confidently deliver production-grade systems with agility.
